Reliable Precision
Redefined
The Best UV Flatbed Printer Made for Speed, Durability and Automation
At DigiTech, we’re committed to providing you with the latest technology in digital UV printing. We have over 30 years of experience in the field and are ready to help you get started on your next digital printing project.
Our UV flatbed printers can print on a wide variety of material. Print direct to rigid board, wood, glass, canvas, painted metal, carpet and so much more. Grand format and UV flatbed printers are an eco-friendly, fast, and cost-effective way to complete your digital printing projects. The team at DigiTech is ready to help you learn everything you need to know about your new UV printer, and how to best use it for your business.
Print Wide Format FAST
Quality UV Printing in Less than 1 Minute
Complete a quality 96"x48" coroplast sign in 58 seconds with our LT3/X3!
From greater distance signage to close up advertisement, the TruFire Precision Print System (PPS) allows complete control of speed and quality. Easily create gap height and print presets for your most used media.
Production Mode
Queue up your day's jobs in one place and use foot pedals to control vacuum and print. Enable auto media lift and auto unload to streamline material handling. This UV printer is designed to optimize your time on every job, big or small.
Automation Ready
Media Unloader Comes Standard
All TruFire UV printer models come standard with a media unloader that can be quickly and easily lowered and stowed as needed. Selected vacuum settings can automatically blow the media upward to ensure static or other obstruction will not hinder the unloading of the media.
Stackers, Conveyers and Cutters
You choose your automation needs, the TruFire is ready to work with it. Ask us about our modular conveyor system today!
Keeping Printheads Safe
Printhead Protection Done Better
Two touch sensing resistor strips (not affected by static electricity) line both sides of the undercarriage for superior head crash protection.
Upon obstruction detection, the carriage is immediately raised up and comes to a soft controlled stop, protecting the printheads from the obstruction and internal components from abrupt stop damage.
TruFire is made to last and printheads are too expensive to be a consumable item.
A UV Printer Built to Last
The flattest, most durable vacuum table ever made
Designed to provide an exceptional degree of flatness and withstand heavy use without harm, easily supporting operators while cleaning the printer. A true 'set it and forget it' flatbed (just don't drop a forklift on it).
Maintenance Free Encoder System
Encoders are built into the rails on both the X and Y-Axis to provide even higher accuracy and maintenance-free performance.
Linear Motors
Digitech was first to use closed faced linear carriage and gantry motors to extend the life of the UV flatbed printer. Digitech takes pride in our printers' value as a durable, simple machine that shows up to work everyday.
Truly Flat and Highly Durable Vacuum Table
- Designed to provide an exceptional degree of flatness.
- Withstands heavy use without harm, easily supporting operators while cleaning the printer.
Accurate to 1 Micron
- X-axis is accurate across the bridge to 1 micron.
- Y-axis is accurate to 1 micron on both sides of the gantry.
Complete Control
- TruFire PPS is an interactive user interface to give the operator complete control.
- Software aided printhead alignment process for easy, accurate alignment.
Built Strong for Precision Printing
- Heavy beam and frame reduce vibration and resonance for sharper, more consistent output.
Enhanced Ink Formulation for Expanded Color Capabilities
- Orange ink broadens the color gamut for richer, more vibrant prints.
- Gray ink enables smoother gradations and subtle transitions.
Safety Enhancements
- Safety zones are configurable to meet varying safety requirements.
- Printing automatically stops and resumes when zones are triggered and cleared.
- Indicator lights on both sides for clear machine status visibility.
Anti-Static Bar and Control Box
- Improves static reduction throughout the print process.
- Continuously reads media surface and adjusts charge to eliminate static buildup.
- Enhances dot placement accuracy, printhead stability, and ink adhesion.
TruFire
Available Models
TruFire UV Flatbed Printers come standard with precision grayscale (4, 6, 10 and 14 picoliters) and automatic unloading. They can also print at a maximum height of 6 inches.
Choose the right size and speed for your UV printing needs with our smaller model printing over 2,000 sq. ft. per hour and our larges model printing over 7,000 sq. ft. per hour.
TruFire LT3/x2
Two staggered rows of 8 print heads
60" x 120" Table Size with 4' x 8' and 5' x 10' vacuum zones
Print Speeds:
Up to 4,376 sq. ft. per hour
(Coro Sign Mode 2 Pass)
Main Ink Reservoir Capacity
Standard: 1.75 liters per Color
Optional: 2.75 liters per Color
Printer Dimensions (L x W x H):
234” x 113” x 70”
(143” W w/ unloader extended)
Weight:
~6,800 lbs.
TruFire LT3/x3
Three staggered rows of 12 print heads
60" x 120" Table Size with 4' x 8' and 5' x 10' vacuum zones
Print Speeds:
Up to 7,389 sq. ft. hr
(Coro Sign Mode 2 Pass)
Main Ink Reservoir Capacity:
2.75 liters per Color
Printer Dimensions (L x W x H):
234” x 127” x 70”
(157” W w/ unloader extended)
Weight:
~8,000 lbs.
TruFire ST2/X1
One row of 6 print heads
50" x 100" Table Size with 48" x 96" and 50" x 100" vacuum zones
Print Speeds:
Up to 2,024 sq. ft. per hour
(Coro Sign Mode 2 Pass)
Main Ink Reservoir Capacity:
Standard: 1.75 liters per Color
Printer Dimensions (L x W x H):
204” x 100” x 70”
(132” W w/ unloader extended)
Weight:
~5,000 lbs.
TruPLOT
Single K Printhead for Penplot accuracy.
Utilized by U.S. Military Contractors
60" x 120" Table Size with 4' x 8' and 5' x 10' vacuum zones
Print Speeds:
Up to 4,376 sq. ft. per hour
(Coro Sign Mode 2 Pass)
Main Ink Reservoir Capacity:
1.75 liters per Color
Printer Dimensions (L x W x H):
234” x 113” x 70”
(143” W w/ unloader extended)
Weight:
~6,500 lbs.
